Czy istnieją granice implantacji natychmiastowej? Cyfrowo planowana i laserowo wspomagana implantacja natychmiastowa w okolicy zęba 16 z jednoczasowym zamkniętym podniesieniem dna zatoki szczękowej oraz augmentacją tkanek twardych i miękkich. Opis przypadku

Marcin Nowosielski

Streszczenie

Artykuł przedstawia opis przypadku leczenia implantoprotetycznego w oko­licy zęba 16 u 41-letniego pacjenta, u którego po wcześniejszym leczeniu za­chowawczym i endodontycznym doszło do niekorzystnego, podkostnego złamania ściany podniebiennej. Ze względu na brak możliwości uzyskania przewidywalnej obręczy protetycznej rokowanie co do odbudowy zęba wła­snego określono jako niekorzystne i zdecydowano o ekstrakcji zęba. Lecze­nie odtwórcze zaplanowano cyfrowo na podstawie badania CBCT, skanu we­wnątrzustnego oraz projektu przyszłej odbudowy protetycznej, zgodnie z za­sadą prosthetically driven implant position. Zaprojektowano dwa szablony chirurgiczne: pierwszy do kontrolowanego przygotowania dostępu pod za­mknięte podniesienie dna zatoki szczękowej, drugi do przygotowania łoża implantu i wprowadzenia wszczepu. Po atraumatycznej ekstrakcji wykona­no laserowe oczyszczenie i dezynfekcję zębodołu z zastosowaniem lase­rów Er:YAG oraz Nd:YAG. Następnie przeprowadzono zamknięte podniesie­nie dna zatoki szczękowej, augmentację materiałem typu sticky bone przy­gotowanym z The Graft oraz i-PRF, a także wszczepienie implantu IS-II acti­ve (Neobiotech) 5,0 × 10,0 mm. Ze względu na niewystarczającą stabilizację pierwotną implant pozostawiono do gojenia zamkniętego, a okolicę zabiego­wą zamknięto płatem uszypułowanym z podniebienia. Po 3,5 miesiąca uzy­skano stabilizację implantu ISQ 85 (Implant Stability Quotient), odsłonięto im­plant, przykręcono śrubę gojącą, wykonano cyfrowy projekt korony oraz final­ną odbudowę protetyczną. Kontrola po miesiącu od oddania pracy wykazała prawidłowy stan kliniczny tkanek miękkich oraz stabilny efekt funkcjonalny.

Abstract

This article presents a case report of implant-prosthetic treatment in the re­gion of tooth 16 in a 41-year-old patient with an unfavorable subcrestal pala­tal wall fracture after previous restorative and endodontic treatment. Due to the inability to obtain a predictable ferrule effect, the prognosis for restoring the tooth was considered unfavorable. Treatment was planned digitally on the basis of CBCT, an intraoral scan and the design of the future prosthetic restoration, according to the prosthetically driven implant position principle. Two surgical guides were designed: one for controlled preparation of access for closed sinus floor elevation and the other for implant osteotomy and im­plant placement. After atraumatic extraction, the socket was cleaned and di­sinfected using Er:YAG and Nd:YAG lasers. Closed sinus floor elevation, au­gmentation with sticky bone prepared from The Graft and i-PRF, and place­ment of a Neobiotech IS-II active 5.0 × 10.0 mm implant were performed. Due to insufficient insertion torque, the implant was left for submerged healing and the surgical site was closed with a palatal pedicled flap. After 3.5 mon­ths, implant stability reached ISQ 85, the implant was uncovered, a healing abutment was connected, and a digitally designed screw-retained crown was delivered. One-month follow-up showed stable peri-implant soft tissues and a favorable functional outcome.

PIŚMIENNICTWO

1. Hämmerle CH, Chen ST, Wilson TG Jr. Consensus statements and recommended clinical procedures regarding the placement of implants in extraction sockets. Int J Oral Maxillofac Implants. 2004; 19(Suppl): 26-28.

2. Ragucci GM, Elnayef B, Criado-Cámara E i wsp. Immediate implant placement in molar extraction sockets: a systematic review and meta-analysis. Int J Implant Dent. 2020; 6(1): 40.

3. Tan WC, Lang NP, Zwahlen M i wsp. A systematic review of the success of sinus floor elevation and survival of implants inserted in combination with sinus floor elevation. Part II: transalveolar technique. J Clin Periodontol. 2008; 35(8 Suppl): 241-254.

4. Kadkhodazadeh M, Alimardani Y, Azadi A i wsp. Clinical outcomes of implants placed with transcrestal maxillary sinus elevation: a systematic review and meta-analysis. Br J Oral Maxillofac Surg. 2024; 62(8): 685-703.

5. Araújo MG, Lindhe J. Dimensional ridge alterations following tooth extraction. An experimental study in the dog. J Clin Periodontol. 2005; 32(2): 212-218.

6. Tan WL, Wong TL, Wong MC i wsp. A systematic review of post-extractional alveolar hard and soft tissue dimensional changes in humans. Clin Oral Implants Res. 2012; 23(Suppl 5): 1-21.

7. Garber DA, Belser UC. Restoration-driven implant placement with restoration- generated site development. Compend Contin Educ Dent. 1995; 16(8): 796, 798-802, 804.

8. Buser D, Martin W, Belser UC. Optimizing esthetics for implant restorations in the anterior maxilla: anatomic and surgical considerations. Int J Oral Maxillofac Implants. 2004; 19(Suppl): 43-61.

9. Thoma DS, Naenni N, Figuero E i wsp. Effects of soft tissue augmentation procedures on peri-implant health or disease: a systematic review and meta-analysis. Clin Oral Implants Res. 2018; 29(Suppl 15): 32-49.

10. Ravidà A, Arena C, Tattan M i wsp. The role of keratinized mucosa width as a risk factor for peri-implant disease: a systematic review, meta-analysis, and trial sequential analysis. Clin Implant Dent Relat Res. 2022; 24(3): 287-300.

11. Tyndall DA, Price JB, Tetradis S i wsp. Position statement of the American Academy of Oral and Maxillofacial Radiology on selection criteria for the use of radiology in dental implantology with emphasis on cone beam computed tomography. Oral Surg Oral Med Oral Pathol Oral Radiol. 2012; 113(6): 817-826.

12. Bornstein MM, Scarfe WC, Vaughn VM i wsp. Cone beam computed tomography in implant dentistry: a systematic review focusing on guidelines, indications, and radiation dose risks. Int J Oral Maxillofac Implants. 2014; 29(Suppl): 55-77.

13. Tahmaseb A, Wu V, Wismeijer D i wsp. The accuracy of static computer-aided implant surgery: a systematic review and meta-analysis. Clin Oral Implants Res. 2018; 29(Suppl 16): 416-435.

14. Lau K, Fung TKC, Ho DKL i wsp. Accuracy of static and dynamic computer-aided implant surgery for immediate implant placement: a systematic review and meta-analysis. J Prosthodont Res. 2025; 69(4): 472-488.

15. Al-Dabbagh RA, Sindi MA, Sanari MA i wsp. Effect of a circumferential ferrule on the survival and success of endodontically treated teeth restored with fiber posts: a systematic review and meta-analysis. J Prosthet Dent. 2024; 132(6): 1251-1259.

16. Juloski J, Radovic I, Goracci C i wsp. Ferrule effect: a literature review. J Endod. 2012; 38(1): 11-19.

17. Li L, Liu Y, Guo J i wsp. Efficacy of Er:YAG laser as a debridement method in surgical treatment for peri-implantitis: a systematic review. Oral Health Prev Dent. 2023; 21(1): 17-24.

18. Stübinger S. Advances in bone surgery: the Er:YAG laser in oral surgery and implant dentistry. Clin Cosmet Investig Dent. 2010; 2: 47-62.

19. Namour M, El Mobadder M, Magnin D i wsp. Q-Switch Nd:YAG laser-assisted decontamination of implant surface. Dent J (Basel). 2019; 7(4): 99.

20. Franzen R, Gutknecht N, Falken S i wsp. Bactericidal effect of a Nd:YAG laser on Enterococcus faecalis at pulse durations of 15 and 25 ms in dentine depths of 500 and 1,000 μm. Lasers Med Sci. 2011; 26(1): 95-101.

21. Babich O, Lugassy E, Babich M i wsp. The use of platelet-rich fibrin in sinus floor augmentation surgery: a systematic review. J Oral Maxillofac Res. 2024; 15(2): e1.

22. Tony JB, Parthasarathy H, Tadepalli A i wsp. CBCT evaluation of sticky bone in horizontal ridge augmentation with and without collagen membrane – a randomized parallel arm clinical trial. J Funct Biomater. 2022; 13(4): 194.

23. Saleh MHA, Sabri H, Di Pietro N i wsp. Clinical indications and outcomes of sinus floor augmentation with bone substitutes: an evidence-based review. Clin Implant Dent Relat Res. 2025; 27(1): e13400.

24. Li X, Lin SC, Duan SY. The impact of deproteinized bovine bone particle size on histological outcomes in sinus floor elevation: a systematic review and meta-analysis. Int J Implant Dent. 2023; 9(1): 35.

25. Gaspar J, Mazor Z, Bonfante EA. Osseodensification technique in crestal maxillary sinus elevation – a narrative review. Clin Implant Dent Relat Res. 2025; 27(1): e13399.

26. Huwais S, Meyer EG. A novel osseous densification approach in implant osteotomy preparation to increase biomechanical primary stability, bone mineral density, and bone-to-implant contact. Int J Oral Maxillofac Implants. 2017; 32(1): 27-36.

27. Sennerby L, Meredith N. Implant stability measurements using resonance frequency analysis: biological and biomechanical aspects and clinical implications. Periodontol 2000. 2008; 47(1): 51-66.

28. Lages FS, Douglas-de Oliveira DW, Costa FO. Relationship between implant stability measurements obtained by insertion torque and resonance frequency analysis: a systematic review. Clin Implant Dent Relat Res. 2018; 20(1): 26-33.

29. Qu C, Luo F, Hong G i wsp. Effects of photobiomodulation therapy on implant stability and postoperative recovery: a systematic review and meta-analysis. Br J Oral Maxillofac Surg. 2022; 60(5): e712-e721.

30. de Barros DD, Dos Santos Barros Catão JS, Ferreira ACD i wsp. Low-level laser therapy is effective in controlling postoperative pain in lower third molar extractions: a systematic review and meta-analysis. Lasers Med Sci. 2022; 37(5): 2363-2377.

31. Gryka-Deszczyńska M, Grzech-Leśniak Z, Dembicka-Mączka D i wsp. Effects of Er:YAG and Nd:YAG lasers with photobiomodulation on alveolar bone preservation post-extraction: a randomized clinical control trial. Photonics. 2025; 12(8): 817.

32. Esposito M, Grusovin MG, Worthington HV. Interventions for replacing missing teeth: antibiotics at dental implant placement to prevent complications. Cochrane Database Syst Rev. 2013; 2013(7): CD004152.

33. Romandini M, De Tullio I, Congedi F i wsp. Antibiotic prophylaxis at dental implant placement: which is the best protocol? A systematic review and network meta-analysis. J Clin Periodontol. 2019; 46(3): 382-395.
